2–15 Installation
Publication 2711-6.0
Setting Advanced INTERCHANGE Parameters
To specify advanced parameters for drivers:
1. Click the Advanced button from the INTERCHANGE Device
Configuration dialog.
Specifies whether self-diagnostics are run
on KT devices before loading driver
configuration. The default is to perform test.
Specifies whether to use upper MS-DOS
memory for packet buffer space. The
default is to use upper memory.
Allocates number of packet buffers
(1 to 200). Each buffer uses 300
bytes of memory. The default is 20.
Allocates space for the number of
unsolicited messages (0 to 200). The
default is 0, which indicates no space.
Specifies whether to load INTERCHANGE drivers
(executables) into high memory. Drivers are not
loaded until you reboot computer.
Specifies the
memory manager
in use on your
system.
Specifies Enabler to use for the 1784-PCMK on DH+ Device Driver.
Specific Enabler uses PCMKINIT or RSIPCMK.
This enabler requires you to enter the socket number containing
the card in the driver dialog. The INTERCHANGE socket numbers
are (0-7). In Windows 95, the sockets are numbered (0 – 8).
Generic Enabler uses PCENABLE.
This enabler requires that you enter a Memory address and
an IRQ (Interrupt).
2. Edit parameters and click OK.
