Appendix
F
Publication 2711-6.0
Troubleshooting
This appendix contains tips to assist with troubleshooting if problems
occur when:
•
Starting PanelBuilder
•
Downloading to a DOS File
•
Downloading using INTERCHANGE Drivers
Many computers contain power management options and utilities
that affect computer COM ports:
•
POWER.EXE in AUTOEXEC.BAT or CONFIG.SYS
•
option in CMOS setup
•
Windows utility
•
Power icon in Control Panel of Windows 95 (set to None)
For troubleshooting information on your PanelView terminal, see the
Operator Terminals manual.
Running Windows 95
Problem
Cause
Recommended Action
When rebooting your computer after installing
PanelBuilder/INTERCHANGE software, you
get a Windows protection error and your
computer locks up.
The C:\WINDOWS\SYSTEM
directory contains the files
VDF1.386 and V485.386.
Reboot the computer in Safe Mode and delete the
VDF1.386 and V485.386 files.
To enter Safe Mode, press the F5 key when the boot
message ”Starting Windows 95” appears.
