20–17 Terminal and Communication Setup
Publication 2711-6.0
The Power-Up tab in the Terminal Setup dialog defines default
operating parameters for the PanelView terminal on power-up:
•
startup screen for application
•
whether to write object preset values (initial presets or last
terminal state values) to controller
•
screen to display on power-up
•
memory card load conditions
•
configuration settings to use on first power-up after download
To set or change power-up defaults for the terminal:
1. Select the Power-Up tab in the Terminal Setup dialog.
2. From the Startup Screen list box, select the first screen to display
when the application starts in the terminal.
3. Select the Write to Controller on Startup check box if you want to
write preset values for objects to the controller on startup. The
default is to not write values to the controller.
Note: Remote I/O and DeviceNet terminals always write preset
values to the controller on startup. The Write to Controller on
Startup check box is always selected for these terminals.
4. If you select Write to Controller on Startup, you can choose either
Use Terminal Presets or Use Last Terminal States.
Select: To:
Use Terminal Presets Write initial values set by application.
Use Last Terminal States Write values present prior to power-up. This is the
default.
Setting Power-up Options
