1–7 Overview of PanelBuilder
Publication 2711-6.0
Screen Objects Type Description
Move Up Moves cursor up one item in a control list or screen list selector. Static
Move Down Moves cursor down one item in a control list or screen list selector. Static
Home Moves cursor to the first item in a control list or screen list selector. Static
End Moves cursor to the last item in a control list or screen list selector. Static
List Keys➀ Page Up Moves cursor up one page in a scrolling control list or screen list. Static ist e s
Page Down Moves cursor down one page in a scrolling control list or screen list. Static
Backspace Returns cursor to currently highlighted selection in a control or screen list. Static
Enter Displays screen selected from a screen list selector or confirms a control
list selection and sends that selection to the controller. Static
Acknowledge Button Acknowledges the alarm displayed in the Alarm Banner and removes the
Alarm Banner from the terminal display. Dynamic
Clear Button Clears the Alarm Banner from the terminal display without acknowledging
the alarm. Static
Print Button Prints the current message displayed in the Alarm Banner. Static
Alarms
Acknowledge All Button Acknowledges all alarms (current and pending) and removes the Alarm
Banner from the terminal display. Dynamic
Alarm List ➀ Displays a list of triggered alarms. The operator can acknowledge alarms
in the list, clear the list or print the list Dynamic
Print Alarm List Button Prints all alarms in the Alarm List. Static
Clear Alarm List Button Clears the Alarm List. Also clears the Alarm Banner even though the
alarm condition may still exist. Static
Line/Connected Line Creates a line or connected lines. Static
Rectangle Creates a rectangle or square. Static
Circle/Ellipse Creates a circle or ellipse. Static
Freeform Creates a freehand drawing. Static
Graphics Scale Creates scale with tick marks for bar graph or other purpose. Static raphics
Background Text Creates screen titles or background text not linked to object. Static
ISA Symbols Select one of 32 predefined drawings such as a valve to place in an
object or on the screen. Static
Imported Graphics Imports/exports bitmaps created with other programs. Static
➀ PanelView 900, 1000 and 1400 Touch Screen terminals require list keys to move the cursor through a control list, screen list selector, or alarm
list. The list keys are also supported on the keypad versions of these terminals.
