Preface and general information
How to use this System Manual
1.1.1 Information provided by the System Manual
1−3
l
EDSVS9332K−EXT EN 4.0
1.1 How to use this System Manual
1.1.1 Information provided by the System Manual
Target group
This System Manual is directed at all persons who design, install, commission and adjust the
9300 servo cam profilers.
Together with the System Manual, document number EDSVS9332K, and the catalogue, it forms the
project planning basis for the manufacturer of plants and machinery.
Contents
The System Manual (Extension) completes the System Manual, document number EDSVS9332K:
l The features and functions are described in detail.
l It describes additional possible applications in detail.
l The parameter setting for typical applications is explained with the help of examples.
l In case of doubt, the Mounting Instructions supplied with the 9300 servo cam profiler are valid.
Contents of System Manual Contents of System Manual (Extension)
1 Preface 1 Preface
2 Safety instructions −
3 Technical data −
4 Installation of the standard device −
5 Wiring of the standard device −
6 Commissioning −
7 Parameter setting −
8 Configuration 2 Configuration
8.1 Monitoring 2.1 Configuration with Global Drive Control
8.2 Monitoring functions 2.2 Basic configurations
8.3 Code table 2.3 Operating modes
8.4 Selection lists
8.5 Table of attributes
− 3 Function library
− 4 Application examples
9 Troubleshooting and fault elimination −
10 DC−bus operation −
11 Safe standstill −
12 Accessories −
13 Appendix 5 Appendix
