Function library
Function blocks
3.2.68
Speed setpoint conditioning (NSET)
3−222
l
EDSVS9332K−EXT EN 4.0
3.2.68.2
JOG setpoints
l
Are fixed values which are saved in the memory.
l
JOG values can be retrieved from the memory via the inputs NSET−JOG*x.
l
The inputs NSET−JOG*x are binary coded so that 15 JOG values can be retrieved.
l
The decoding for enabling the JOG values (retrieval from the memory) is carried out according
to the following table:
Output signal
1st input
NSET−JOG*1
2nd input
NSET−JOG*2
3rd input
NSET−JOG*4
4th input
NSET−JOG*8
NSET−N
0
0
0
0
JOG 1
1
0
0
0
JOG 2
0
1
0
0
JOG 3
1
1
0
0
JOG 4
0
0
1
0
JOG 5
1
0
1
0
JOG 6
0
1
1
0
JOG 7
1
1
1
0
JOG 8
0
0
0
1
JOG 9
1
0
0
1
JOG 10
0
1
0
1
JOG 11
1
1
0
1
JOG 12
0
0
1
1
JOG 13
1
0
1
1
JOG 14
0
1
1
1
JOG 15
1
1
1
1
l
When all inputs are assigned with 0, the input NSET−N is active.
l
The number of inputs that must be assigned depends on the required number of JOG
setpoints. Four inputs and thus 15 possible selections are available. A digital signal source is
assigned via C0787 and the corresponding subcode.
Number of required JOG setpoints
Number of inputs to be assigned
1
At least 1
1 ... 3
At least 2
4 ... 7
At least 3
8 ... 15
4
