Function library, Function blocks, 88 angle value selection (selph) – Lenze EVS9332xK User Manual
Page 311: Selph2, Function
Function library
Function blocks
3.2.88
Angle value selection (SELPH)
3−283
l
EDSVS9332K−EXT EN 4.0
SELPH2
SELPH2-IN1
SELPH2
C1667/1
C1669/1
SELPH2-OUT
SELPH2-SELECT
C1666
C1668
SELPH2-IN2
C1667/2
C1669/2
SELPH2-IN3
C1667/3
C1669/3
SELPH2-IN4
C1667/4
C1669/4
SELPH2-IN5
C1667/5
C1669/5
SELPH2-IN6
C1667/6
C1669/6
SELPH2-IN7
C1667/7
C1669/7
SELPH2-IN8
C1667/8
C1669/8
FIXED0INC
1
2
3
4
5
6
7
8
0
8
C1665
0
Fig. 3−229
Function block SELPH2
Signal
Source
Note
Name
Type
DIS
DIS format
CFG
List
SELPH2−SELECT
a
C1668
dec
C1666
1
−
SELPH2−IN1
ph
C1669/1
dec [inc]
C1667/1
3
−
SELPH2−IN2
ph
C1669/2
dec [inc]
C1667/2
3
−
SELPH2−IN3
ph
C1669/3
dec [inc]
C1667/3
3
−
SELPH2−IN4
ph
C1669/4
dec [inc]
C1667/4
3
−
SELPH2−IN5
ph
C1669/5
dec [inc]
C1667/5
3
−
SELPH2−IN6
ph
C1669/6
dec [inc]
C1667/6
3
−
SELPH2−IN7
ph
C1669/7
dec [inc]
C1667/7
3
−
SELPH2−IN8
ph
C1669/8
dec [inc]
C1667/8
3
−
SELPH2−OUT
ph
−
−
−
−
−
−
−
C1665
dec
−
−
Displays the current selection
Function
l
An analog signal at SELPHx−SELECT directly selects an input and switches it to SELPHx−OUT.
– If SELPHx−SELECT = 0, SELPHx−OUT switches to FIXED 0 INC.
– If SELPHx−SELECT < 0, SELPHx−OUT switches to FIXED 0 INC.
– If SELPHx−SELECT > 8, SELPHx−OUT switches to SELPHx−IN8.
Tip!
You can select an input via a digital signal by connecting the FB CONVDAx upstream of
SELPHx−SELECT.
