Function library
Function blocks
3.2.78 Phase integrator (PHINT5)
3−250
l
EDSVS9332K−EXT EN 4.0
Signal Source Note
Name Typ
e
DIS DIS
format
CFG List
PHINT5−X−OFFSET ph C1183/7 dec [inc] C1182/7 3 Selection of an offset for the X direction
PHINT5−H−VALUE ph C1183/5 dec [inc] C1182/5 3 Upper limit value of the integrator
Only positive input values are permissible.
A check for negative values is not carried out.
PHINT5−X−SET ph C1183/4 dec [inc] C1182/4 3 Setpoint with which the integrator is to start.
PHINT5−LOAD d C1181/4 bin C1180/4 2 A LOW−HIGH edge loads the integrator with the value at PHINT5−X−SET,
then the integrator continues running immediately.
PHINT5−RESET d C1181/3 bin C1180/3 2 HIGH:
·
The integrator is reset to the value at PHINT5−X−SET.
·
The touch probe function is deactivated. Available touch probe
requirements are reset.
·
PHINT5−TP−SYNC−BUSY, PHINT5−X0, and PHINT5−TP−RECOGN are
set to LOW.
PHINT5−NUM a C1189/1 dec [%] C1188/1 1 Numerator for evaluation of the input signal at PHINT5−DFIN.
PHINT5−DFIN phd C1185/1 dec [rpm] C1184/2 4 Master speed input
·
A positive value at PHINT5−DFIN increases the value at PHINT5−OUT
·
A negative value at PHINT5−DFIN decreases the value at
PHINT5−OUT
PHINT5−DENOM a C1189/2 dec [%] C1188/2 1 Denominator for evaluation of the input signal at PHINT5−DFIN.
PHINT5−TP−SPEED−LIM phd C1185/2 dec [rpm] C1184/3 4 Selection of a compensation speed.
The input signal is active if PHINT5−TP−SYNC−BUSY = HIGH and
C1740 = 1.
It is impermissible to select constant values (e.g. via free codes
(FCODE)).
PHINT5−TP−POS ph C1183/6 dec [inc] C1182/6 3 Distance of the touch probe position to the zero point of the integrator.
PHINT5−TP−ENABLE d C1181/5 bin C1180/5 2 HIGH: The touch probe signal is evaluated.
LOW: The touch probe signal is not evaluated.
PHINT5−TP−EDGE−SELEC
T d C1181/6 bin C1180/6 2 LOW: The HIGH−LOW edge of the input signal at X5/E4 or X5/E5 is
evaluated.
HIGH: The LOW−HIGH edge of the input signal at X5/E4 or X5/E5 is
evaluated.
PHINT5−OUT ph Integrator position + offset of PHINT5−X−Offset.
The output signal is placed between 0 (fixedly) and the specified limit
value at PHINT5−H−VALUE.
PHINT5−DFOUT phd Speed signal + offset of PHINT5−X−Offset.
PHINT5−DFOUT−INIT d HIGH: The output PHINT5−DFOUT is within the limitation ±29999 rpm
PHINT5−X0 d LOW−HIGH edge: Zero crossing of the integrator. The zero crossing is
only signalised for one cycle (1 ms).
PHINT5−X−DIFF ph Outputs the difference between the integrator and the signal at
PHINT5−TP−POS if a touch probe pulse occurs.
The output only is effected if PHINT5−ENABLE−TP is set = HIGH.
PHINT5−TP−DIFF ph Outputs the distance between 2 successive touch probe pulses (relating
to the integrator)
The output only is effected if PHINT5−ENABLE−TP is set = HIGH.
PHINT5−TP−DIST ph Outputs the distance of the touch probe pulse to the zero point of the
integrator
The output only is effected if PHINT5−ENABLE−TP is set = HIGH.
PHINT5−TP−SYNC−BUSY d Touch probe evaluation:
LOW: No deviation measured, or the deviation has already been
compensated
HIGH: There is a deviation between the integrator and the input signal
at PHINT5−TP−POS that has not been compensated. The compensation
speed at PHINT5−TP−SPEED−LIM is activated if C1740 is set to 1.
LOW−HIGH edge: compensation process completed
PHINT5−TP−RECOGN d Signalises a recognised touch probe pulse.
LOW−HIGH edge: Compensation process completed. The signal is
output for one cycle (1 ms).
