Configuration
Basic configurations
2−4
l
EDSVS9332K−EXT EN 4.0
2.2 Basic configurations
(
Stop!
It is possible to load predefined basic configurations via code C0005. If you load a
configuration via C0005, the assignment of all inputs and outputs will be overwritten
with the corresponding basic assignment.
Adapt the function assignment to the wiring.
The internal signal processing is adapted to the drive task by selecting a predefined basic
configuration. You can, for instance, use the Lenze setting for speed control.
l A detailed description of the basic configurations with terminal assignments, signal flow
diagrams, and application examples can be found in the chapter "Application examples".
l Before loading a basic configuration via C0005, the controller must be inhibited.
Several predefined signal configurations can be loaded by using code C0005. The selection numbers
have the following meaning:
C0005 = 1 X X X X
Control
0 − Terminal control
1 − Control via LECOM A/B/LI
3 − Control via AIF (INTERBUS,PROFIBUS)
5 − Control via system bus (CAN)
Terminal supply
0 − External supply of control terminals
1 − Internal supply of control terminals
Additional functions (see chapter 2.2.2 ff.)
0 − None
1 − Homing function
2 − Clutch function
3 − Switching points
8 − Mark−controlled correction of the master value
9 − Mark−controlled correction of the act. value
Operating mode
0 − Replacement of a mechanical cam* (see chapter 2.2.3)
1 − Welding bar drive* (see chapter 4.2)
2 − Operation with position storage* (see chapter 2.2.5)
* − Incremental master value
Identification
1 − Cam profile
