Application examples
4.3 Filling process
4−8
l
EDSVS9332K−EXT EN 4.0
4.3 Filling process
Select the basic configuration C0005 = 13000 or C0005 = 13300 for this application example.
0
1
9300kur047
Fig. 4−6 Schematic diagram of a filling device
0
Pump drive (cam drive)
1 Feed drive
ƒ ‚

9300kur045
Fig. 4−7 Profile of the pump drive (in principle)
 Machine cycle of pump drive
‚ Pump drive: standstill phase (drive is at standstill)
Feed drive: feed phase (drive moves)
ƒ Filling process (pump drive moves)
