Function library
Function blocks
3.2.36
Profile selection (CSEL)
3−128
l
EDSVS9332K−EXT EN 4.0
3.2.36.1
Change of the input bit pattern
1st input
CSEL1−CAM*1
2nd input
CSEL1−CAM*2
3rd input
CSEL1−CAM*4
CSEL1−LOAD
CSEL1−Event
Output
CSEL1−OUT
0
0
0
0
³
1
0
0
1
0
0
0
³
1
0
1
0
1
0
0
³
1
0
2
1
1
0
0
³
1
0
3
0
0
1
0
³
1
0
4
1
0
1
0
³
1
0
5
0
1
1
0
³
1
0
6
1
1
1
0
³
1
0
7
*
*
*
*
1
Value in C1420
* − Signal status has no meaning
l
Depending on the number of profiles used, not all inputs must be assigned for the profile
selection.
Number of profiles used
(value of C1300)
Inputs to be assigned
(CAM*1, CAM*2, CAM*4)
1 (only profile 0)
0
2 (profiles 0 and 1)
1 (CAM*1)
4 (profiles 0 to 3)
2 (CAM*1, CAM*2)
8 (profiles 0 to 7)
3 (CAM*1, CAM*2, CAM*4)
3.2.36.2
Acceptance of the converted value
Very often, a new profile is selected during operation. This new profile, i.e. the changed value, must
only be accepted if the drive reaches a certain position. The acceptance is activated by a L
³H edge
at the input CSEL1−LOAD.
3.2.36.3
Event−dependent output of a fixed value
l
The value entered under C1420 will be output at CSEL1−OUT (without signal edge at
CSEL1−LOAD) when the input CSEL1−EVENT is selected.
Stop!
The activation of a cam profile, which has been additionally defined in CSEL but exceeds the number
of profiles selected in the FB CDATA, will be ignored.
Example: Input in CDATA = 4 profiles; profile additionally defined in CSEL (profile 5).
The special profile would be ignored!
Code
Meaning
Note
C1420
Input of fixed values for the selection through
CSEL1−EVENT
If the signal at input CSEL1−EVENT = LOW, a L
³H edge must again be set at the input CSEL1−LOAD
to accept.
