Configuration
Configuration with Global Drive Control
2−3
l
EDSVS9332K−EXT EN 4.0
2.1
Configuration with Global Drive Control
With Global Drive Control (GDC), Lenze offers an easy−to−understand, clearly−laid−out and
convenient tool for the configuration of your specific drive task.
Function block library
GDC provides an easy−to−read library of available function blocks (FB). GDC also displays the
complete assignment of an FB.
Signal configuration
The signal configuration is done with only one dialog box. It is a convenient way
l
to display every FB as a block diagram.
l
to see the assignment of all signal inputs at a glance.
l
to enter the FB in the processing table.
l
to print your signal configuration.
Terminal assignment
Freely assignable terminals can be configured using two dialog boxes:
l
Dialog box − to link digital inputs and outputs.
l
Dialog box − to link analog inputs and outputs.
