Function library
Function blocks
3.2.63 Motor phase failure detection (MLP)
3−210
l
EDSVS9332K−EXT EN 4.0
3.2.63 Motor phase failure detection (MLP)
Purpose
Motor phase monitoring.
MLP1
Fig. 3−158 Motor phase failure detection (MLP1)
Code LCD Possible settings Important
Lenze Selection
C0597 MONIT LP1 3 0 Trip
2 Warning
3 Off
Conf. LP1
Configuration of motor phase failure
monitoring
C0599 LIMIT LP 1 5.0 1.0 {0.1} 10.0 Current limit LP1
Current limit for motor phase failure
monitoring
Function
Detailed descriptions concerning monitoring/fault messages can be found in part E (Troubleshooting
and fault elimination) of the System Manual.
The function block MLP1 must be entered into the processing table if the motor phase failure
detection is to be used.
