Function library
Function blocks
3.2.101 Positioning control (VTPOSC)
3−322
l
EDSVS9332K−EXT EN 4.0
Function
52 table positions are available.
l Enter fixed position values in m_units under C1476/x
– 16 table positions (VTPOSC−No1 ... VTPOSC−No16) are available.
l Enter fixed position values in s_units under C1477/x
– 16 table positions (VTPOSC−No17 ... VTPOSC−No32) are available.
l Enter fixed position values in [inc] under C0474.
– 10 table positions (VTPOSC−No33 ... VTPOSC−No42) are available.
l Enter variable position target values via VTPOS−INx.
– 10 table positions (VTPOS−No43 ... VTPOS−No52) are available.
– Signal input via function blocks
– The position target values must be transmitted to the table positions before the
corresponding program set starts and accesses these values.
Note!
Entries in the processing table are only required if FB inputs and outputs are used.
