Function library
Function blocks
3.2.3 Function block CDATA
3−22
l
EDSVS9332K−EXT EN 4.0
Signal Note Source
Name List CFG DIS format DIS Typ
e
CDATA−ACTLEN ph Output of the actual master value clock pulse length (65536 inc. = 1 encoder rev.)
CDATA−LEN1 1) ph Output of the actual X length of section 1 of the selected profile (65536 inc. = 1
encoder rev.)
CDATA−LEN2 1) ph Output of the actual X length of section 2 of the selected profile (65536 inc. = 1
encoder rev.)
CDATA−LEN3 1) ph Output of the actual X length of section 3 of the selected profile (65536 inc. = 1
encoder rev.)
CDATA−LEN4 1) ph Output of the actual X length of section 4 of the selected cam profile (65536 inc =
1 encoder rev.)
CDATA−LEN5 1) ph Output of the actual X length of section 5 of the selected cam profile (65536 inc =
1 encoder rev.)
CDATA−YOUT ph C1334
C1330/1
Drive setpoint position (65536 inc. = 1 motor revolution)
CDATA−N−SYNCH phd Link for synchronised compression/stretching
CDATA−NOUT phd Drive setpoint speed
For the "stretching and compression" function you have to preselect the limitation
of the output signal in C1295.
·
Stretching and compression £ 100 %
– Set C1295 = 0: the output signal is limited to ±29999 rpm (Lenze setting).
·
Stretching and compression > 100 %
– Set C1295 = 1: the output signal is limited to ±14999 rpm.
CDATA−Y−END ph Y end value of the actual profile (65536 inc. = 1 motor revolution)
CDATA−YOUT−CYCLE ph C1330/2 Current value of the drive setpoint position within the limits of the profile
(65536 inc. = 1 motor revolution)
CDATA−X−ACT ph C1329/1 Current position of the master shaft / master angle
CDATA−X−NOUT phd X−axis as speed, without jump back if C1332 = 0 (master value of CDATA−DFIN) is
selected
CDATA−INIT−NOUT d This output refers to the motor. Do not enable the drive after mains
connection before CDATA−INIT−NOUT = LOW!
HIGH: the drive speed does not reach the setpoint defined by the position output.
During this deviation which may last over several cycles, a great position change
is output at the speed output. Increments do not get lost!
CDATA−INIT−X−NOUT d This output refers to the master axis. Do not enable the drive after mains
connection before CDATA−INIT−X−NOUT = LOW!
(for further description see CDATA−INIT−NOUT)
CDATA−XPOS ph C1333 Output of the master value integrator (65536 inc. = 1 encoder rev.)
CDATA−X−DIFF ph Outputs the difference between the integrator and the signal at CDATA−TP−POS if a
touch probe pulse occurs.
CDATA−TP−DIFF ph C1329/3 Touch−Probe mode of cross cutter, current angular difference between TP position
and actual X axis position
CDATA−TP−DIST ph C1329/4 Touch−Probe mode of cross cutter, distance between the last two TP positions
CDATA−TP−SYNC−BUSY d Compensation between TP position and current X axis position active (with
adjusted compensation speed)
CDATA−TP−RECOGN 1) d Output is HIGH for 1 ms if a HIGH−LOW edge occurs at X5/E5 and
CDATA−X−TP/E5 = HIGH
