Appendix
5.2 Index
5−5
l
EDSVS9332K−EXT EN 4.0
5.2 Index
A
Absolute value generator (ABS), 3−37
Actual angle integrator (PHDIFF), 3−240
Addition block (ADD), 3−38
Addition block (ADDPHD1), 3−39
Additional setpoint, 3−225
Additional torque setpoint, 3−192
Analog input (AIN), 3−45
Analog output (AOUT), 3−53
Analog signal changeover switch (ASW), 3−59
AND operation (AND), 3−47
angle addition block (PHADD), 3−237
Angle comparator (PHCMP), 3−238
Angle controller, Influence of angle controller,
3−196
Angle conversion (CONVPHA), 3−115
Angle conversion (CONVPHAA), 3−118
Angle conversion (CONVPHPH), 3−122
Angle integrator (PHINT)
− constant input value, 3−244
− input value with sign reversal, 3−246
− Scaling of PHINTx−OUT, 3−247
Angle integrator (PHINT1,2,3), 3−242
Angle integrator (PHINT4), 3−248
Angle signal adaptation (PHDIV), 3−241
Angle signal changeover switch (SWPH), 3−303
Application examples, i
Arithmetic block (ARIT), 3−55
Automation interface (AIF−IN), 3−40
Automation interface (AIF−OUT), 3−43
C
Cam profile selection (CSEL), 3−127
CDATA, 3−20
Characteristic function (CURVE), 3−129
Characteristic function (CURVEC), 3−132
Clutch (CLUTCH 3), 3−91
− disengaging immediately, 3−93
− engaging the clutch, 3−100
− fault messages, 3−93
− minimum speed, 3−94
− selection of the disengaging position, 3−96
− selection of the target position in the disengaged state, 3−97
− time−controlled disengaging at disengaging position, 3−99
− time−controlled disengaging in target position, 3−97
− time−controlled engaging, 3−95 , 3−102
Comparator (CMP), 3−103
Configuration, 2−1
− Basic configurations, 2−4
− Function blocks, 3−5
− Function library, 3−1
− Global Drive Control, 2−3
Configuration 10000, 2−9
Control characteristic, 3−235
Controller inhibit (CINH), 3−139
Conversion (CONVPHPHD1), 3−123
Conversion (CONVPHPHD2), 3−124
Conversion stretch factor (CONVPHD), 3−120
Current controller, 3−192
CW/CCW/QSP linking (R/L/Q), 3−260
D
Dead band(DB), 3−136
Definition of notes used, 1−5
Definitions, Terms, 5−14
Delay element (PT1−1), 3−257
Delay element (PT1−2), 3−258
Delay elements (DIGDEL), 3−158
Derivative−action element (DT1), 3−163
Digital frequency changeover switch (SWPHD),
3−304
Digital frequency input (DFIN), 3−141
Digital frequency output (DFOUT), 3−144
Digital frequency processing (DFSET), 3−154
Digital frequency ramp function generator
(DFRFG), 3−148
Digital inputs (DIGIN), 3−161
Digital outputs (DIGOUT), 3−162
