Function library
Function blocks
3.2.12 Analog output via terminal 62/63 (AOUT)
3−54
l
EDSVS9332K−EXT EN 4.0
Example for an output value
AOUT1−IN = 50%, AOUT1−GAIN = 100%, AOUT1−OFFSET = 10%
Output terminal 62 = ((50% * 100% = 50%) + 10% = 60%) = 6 V
AOUT−GAIN
AOUT−IN
OUT
ООООО
AOUT−OFFSET
Fig. 3−38 Offset and gain of the analog output
