3.2.3 Function block CDATA
3−21
l
EDSVS9332K−EXT EN 4.0
Signal Source Note
Name Typ
e
DIS DIS format CFG List
CDATA−SEL a C1321/3 dec [abs] C1320/3 1 Profile selection, 0 = profile 0 (1st profile)
CDATA−SEL−CAM−MODE d C1323/15 bin C132215 2 HIGH: profile changeover while travelling the profile. Hence, clutch functions can
be implemented via profiles.
CDATA−HOLD d C1323/6 bin C1322/6 2 HIGH: prevents profile switching, input has priority over CDATA−RESET
CDATA−CYCLE d C1323/1 bin C1322/1 2 Automatic profile switching
LOW: profile selection from input CDATA−SEL is active
HIGH: the profiles from C1311 and C1312 are cyclically processed
CDATA−RESET d C1323/2 bin C1322/2 2 If CDATA−RESET = HIGH and CDATA−CYCLE = LOW, the input CDATA−SEL is
evaluated immediately
If CDATA−RESET = HIGH and CDATA−CYCLE = HIGH, the profile from C1311 is
processed
CDATA−LOAD d C1323/7 bin C1322/7 2 Loaded profiles accepted with LOW−HIGH edge
CDATA−TEACH d C1323/13 bin C1322/13 2 Teach function, contact Lenze
CDATA−REL−SEL d C1323/3 bin C1322/3 2 HIGH: feed function active (relative positioning)
CDATA−YIN ph C1325/6 dec [inc] C1324/6 3 Input for the teach function, contact Lenze
CDATA−OFFS−XIN ph C1325/7 dec [inc] C1324/7 3 Offset on input CDATA−XIN if C1338 = 1 has been selected
CDATA−XIN ph C1325/2 dec [inc] C1324/2 3 Input for master value position if C1332 = 1
CDATA−XOFFS ph C1325/3 dec [inc] C1324/3 3 Input for offset in X direction (only if C1332 = 0)
CDATA−X−START ph C1325/1 dec [inc] C1324/1 3 Input for the profile starting position on the X axis
CDATA−X−RESET d C1323/4 bin C1322/4 2 HIGH: sets the master value integrator to the value at input CDATA−X−START
CDATA−DFIN phd C1327/1 dec [rpm] C1326/1 4 Input for digital frequency if C1332 = 0
CDATA−XFACT a C1321/2 dec [%] C1320/2 1 Stretching/compression factor
+100 % = no compression/stretching, >100 % = compression,
<100 % = stretching
CDATA−TP−SPEED−LIM phd C1327/2 dec [rpm] C1326/2 4 Selection of a compensation speed. Input is activated via C1296.
It is impermissible to select constant values, e.g. via free codes (FCODE).
CDATA−TP−POS ph C1325/4 dec [inc] C1324/4 3 Touch probe position of the master value (only if C1332 = 0)
CDATA−TP−DISABLE d C1323/14 C1322/14 HIGH: suppression of touch probe
CDATA−X−TP/E5 d C1323/8 − − − Selection of the touch probe source (only for synchronisation)
LOW: source CDATA−X−TP
HIGH: terminal X5/E5
CDATA−X−TP d C1323/5 bin C1322/5 2 LOW−HIGH edge sets master value integrator to position of input CDATA−TP−POS
CDATA−TP−EDGE−SELECT d C1323/16 bin C1322/16 2 LOW: HIGH−LOW edge of the input signal at X5/E4 is evaluated.
HIGH: LOW−HIGH edge of the input signal at X5/E5 is evaluated.
CDATA−ACTCAM a Output of the active profile
CDATA−ERR−NR a Display of the error number from the teach function
CDATA−BUSY d LOW−HIGH edge: the interpolation point distribution is not optimal, select fewer
points
CDATA−BUSY−LENx d HIGH: CDATA−LENx and CDATA−Y−END are not valid and are being determined at
present (e.g. profile switching)
CDATA−LOAD−BUSY d HIGH: new profile data is being accepted at present, the controller is inhibited
(only if input CDATA−LOAD = HIGH)
CDATA−LOAD−RDY d Handshake signal for reloading profiles
CDATA−LOAD−ERR d HIGH: error in the current profile at check via C0500
CDATA−LOAD−ERR−NR d HIGH: error in the current profile at check via C0500
CDATA−CHK−ERR d HIGH: the checksum transferred to C0509 does not correspond to the profile data
CDATA−CHK−BUSY d HIGH: profile checksum checking is active and not yet completed
CDATA−X0 d LOW−HIGH edge: zero crossing of the master value integrator
CDATA−X<0 d HIGH: number range exceeded in X direction
CDATA−X>XMAX d HIGH: number range exceeded in X direction
CDATA−SEC1 1) d HIGH: section 1 active
CDATA−SEC2 1) d HIGH: section 2 active
CDATA−SEC3 1) d HIGH: section 3 active
CDATA−SEC4 1) d HIGH: section 4 active
CDATA−SEC5 1) d HIGH: section 5 active
CDATA−X0−CYCLE d LOW−HIGH edge: zero crossing of the master value integrator when a profile cycle
from C1311 and C1312 is processed.
CDATA−TEACH−BUSY d Teach function, contact Lenze
CDATA−TEACH−ACTIVE d Teach function, contact Lenze
