Angle signal changeover switch (SWPH1 and SWPH2)
3−303
l
EDSVS9332K−EXT EN 4.0
3.2.96
Angle signal changeover switch (SWPH1 and SWPH2)
Changeover switch for selecting between two angle signals
0
1
C 1 1 0 8 / 1
C 1 1 0 8 / 2
C 1 1 0 6 / 1
C 1 1 0 7 / 1
C 1 1 0 9 / 2
C 1 1 0 9 / 1
S W P H 1 - I N 1
S W P H 1 - I N 2
S W P H 1 - S E T
S W P H 1
S W P H 1 - O U T
Signal
Source
Note
Name
Type
DIS
DIS format
CFG
List
SWPH1−IN1
ph
C1109/1
dec [inc]
C1108/1
3
–
SWPH1−IN2
ph
C1109/2
dec [inc]
C1108/2
3
–
SWPH1−SET
d
C1107/1
bin
C1106/1
2
–
SWPH1−OUT
ph
–
–
–
–
–
0
1
C 1 1 0 8 / 3
C 1 1 0 8 / 4
C 1 1 0 6 / 2
C 1 1 0 7 / 2
C 1 1 0 9 / 4
C 1 1 0 9 / 3
S W P H 2 - I N 1
S W P H 2 - I N 2
S W P H 2 - S E T
S W P H 2
S W P H 2 - O U T
Signal
Source
Note
Name
Type
DIS
DIS format
CFG
List
SWPH2−IN1
ph
C1109/3
dec [inc]
C1108/3
3
–
SWPH2−IN2
ph
C1108/4
dec [inc]
C1108/4
3
–
SWPH2−SET
d
C1106/2
bin
C1107/2
2
–
SWPH2−OUT
ph
–
–
–
–
–
Function
l
Different signals are assigned to the inputs SWPHx−IN1 and −IN2. One of the signals can be
assigned to the output SWPHx−OUT.
l
The input is selected with SWPHx−SET
– SWPHx−SET = LOW:
Input SWPHx−IN1
– SWPHx−SET = HIGH:
Input SWPHx−IN2
