Lenze EVS9332xK - Manual (Page 139)

Function library
Function blocks
3−111
l
EDSVS9332K−EXT EN 4.0
CONV6
C O N V 6
C O N V 6 - O U T C O N V 6 - I N
C 1 1 7 3
C 1 1 7 2
C 1 1 7 0
C 1 1 7 1
Fig. 3−83 Function block CONV6
Signal Source Note
Name Type DIS DIS format CFG List Lenze
CONV6−IN a C1173 dec [%] C1172 1 1000
CONV6−OUT phd − − − − − Limited to ±29999 rpm
This function block is used to convert analog signals into speed signals.
Conversion according to formula:
CONV6−OUT + CONV6−IN @
15000 rpm
100 %
@ C1170
C1171
CONV7
CONV7
CONV7−DFOUT CONV7−DFIN
C1457
C1456
C1458
C1459
FB_conv7
Fig. 3−84 Function block CONV7
Signal Source Note
Name Type DIS DIS format CFG List Lenze
CONV7−DFIN phd C1457 dec [%] C1456 1 1000
CONV7−DFOUT phd − − − − − Limited to ±29999 rpm
This function block is used to convert analog signals into speed signals.
Conversion according to formula:
CONV7−DFOUT + CONV7−DFIN @ C1458
C1459
[ rpm ]
