Application examples
4.1 Replacement of a mechanical cam
4−3
l
EDSVS9332K−EXT EN 4.0
4.1 Replacement of a mechanical cam
Select the basic configuration C0005 = 10000 for this application example.
Y
S
S
Y
Y
1 0
9300kur052
Fig. 4−1 Principle of the mechanical and electronic cam
0
Mechanical cam
1 Electronic cam
j Master angle
Y Setpoint position
S Camshaft controller
+UG -UG
X4
HI
X5
93XX
-
DC 24V
M
RS
3 9
+
GND LO 59 39
U L1
0
L2 L3 V W X7
A1A2A3A4 28 E1E2E3E4E5
X9
9300kur029
Fig. 4−2 Wiring principle for the controller
0 Master value encoder
RS Resolver
Features
l Optimum adaptation of motion sequences to the process
l Easy changeover in the case of product changes
l Master value via incremental encoder
