Function library
Function blocks
3.2.1 Table of function blocks
3−14
l
EDSVS9332K−EXT EN 4.0
3.2 Function blocks
3.2.1 Table of function blocks
Function block Description CPU time
[ ms]
Used in basic configuration C0005
1000 10000 11000 12000
ABS1 Absolute value generator ^ 3−37 4 · · ·
ADD1 Addition block ^ 3−38 8
ADDPHD1 Addition block ^ 3−39 9
AIF−IN Fieldbus ^ 3−40 60
AIF−OUT Fieldbus ^ 3−43 56 · · · ·
AIN1 Analog input X6/1, X6/2 ^ 3−45 10
AIN2 Analog input X6/3, X6/4 28
AND1 Logic AND, block 1
^ 3−47
6
AND2 Logic AND, block 2
AND3 Logic AND, block 3
AND4 Logic AND, block 4
AND5 Logic AND, block 5
AND6 Logic AND, block 6
AND7 Logic AND, block 7
AND8 Logic AND, block 8
8
AND9 Logic AND, block 9
ANEG1 Analog inverter 1 ^ 3−52 3 · · · ·
ANEG2 Analog inverter 2
AOUT1 Analog output X6/62 ^ 3−53 12 · · · ·
AOUT2 Analog output X6/63 · · · ·
ARIT1 Arithmetic block 1 ^ 3−55 11
ARIT2 Arithmetic block 2
ARITPH1 32−bit arithmetic block 1
^ 3−56 15
ARITPH2 32−bit arithmetic block 2
ARITPH3 32−bit arithmetic block 3
ARITPH4 32−bit arithmetic block 4
ARITPH5 32−bit arithmetic block 5
ARITPH6 32−bit arithmetic block 6
ASW1 Analog changeover 1
^ 3−59 4
·
ASW2 Analog changeover 2
ASW3 Analog changeover 3
ASW4 Analog changeover 4
BRK Triggering of holding brake ^ 3−61 15
CAN−IN1 System bus
^ 3−66 − CAN−IN2 System bus
CAN−IN3 System bus
CAN−OUT1 System bus
^ 3−66 56
· · · ·
CAN−OUT2 System bus · · · ·
CAN−OUT3 System bus · · · ·
CCTRL Setpoint conditioning ^ 3−67 30 · · ·
CCTRL2 Setpoint conditioning ^ 3−74 45
CDATA Profile data conditioning ^ 3−20 140 · · ·
CERR Following error monitoring ^ 3−82 15 · · ·
CLUTCH1 Virtual clutch 1 ^ 3−85 47
CLUTCH2 Virtual clutch 2 ^ 3−89 30
CLUTCH3 Virtual clutch 3 ^ 3−91 60
CMP1 Comparator 1
^ 3−103
15
·
CMP2 Comparator 2
CMP3 Comparator 3 15
