Function library
Function blocks
3−109
l
EDSVS9332K−EXT EN 4.0
CONV2
C 0 9 4 7
C 0 9 4 8
C O N V 2 - I N
C O N V 2 - O U T
C O N V 2
C 0 9 4 5
C 0 9 4 6
C O N V 2 - D F O U T
FB_conv2
Fig. 3−79
Function block CONV2
Signal
Source
Note
Name
Type
DIS
DIS format
CFG
List
Lenze
CONV2−IN
a
C0948
dec [%]
C0947
1
1000
CONV2−OUT
a
−
−
−
−
−
Limited to ±199.99 %
CONV2−DFOUT
phd
−
−
−
−
−
Limited to ±29999 rpm
This function block is used to multiply or divide analog signals.
Conversion according to formula:
CONV2−OUT
+ CONV2−IN @
100 %
15000 rpm
@ C0945
C0946
or
CONV2−DFOUT
+ CONV2−IN @ C0945
C0946
[rpm]
CONV3
C O N V 3
C O N V 3 - O U T
C O N V 3 - I N
C 0 9 5 3
C 0 9 5 2
C 0 9 5 0
C 0 9 5 1
C O N V 3 - D F O U T
Fig. 3−80
Function block CONV3
Signal
Source
Note
Name
Type
DIS
DIS format
CFG
List
Lenze
CONV3−IN
phd
C0953
dec [rpm]
C0952
4
1000
CONV3−OUT
a
−
−
−
−
−
Limited to ±199.99 %
CONV3−DFOUT
phd
−
−
−
−
−
Limited to ±29999 rpm
This function block is used to convert speed signals into analog signals.
Conversion according to formula:
CONV3−OUT
+ CONV3−IN @
100 %
15000 rpm
@ C0950
C0951
or
CONV3−DFOUT
+ CONV3−IN @ C0950
C0951
[rpm]
