Printer Settings
11. PCL SETTINGS* 1 Sets the PCL printer setting.
1. PAPER SAVE Sets whether to save blank pages.
OFF
ON –
–
2. ORIENTATION Sets the paper orientation.
PORTRAIT
LANDSCAPE –
–
3. FONT NUMBER Sets the default font typeface for the printer function using the corresponding font numbers. (0-
91) (See “Typeface Samples,” on p. 11-56.)
4. POINT SIZE Specifies a point size for the default font. This item appears when the number in NUMBER> is that of a proportionally spaced scalable font. (4.00 cpi–999.75 cpi)
5. PITCH Specifies the pitch for the default font. This item appears when the number in
is that of a fixed pitch scalable font. (00.44 point–99.99 point)
6. FORM LINES Sets the number of lines to be printed on a page. (5 lines-128 lines)
7. SYMBOL SET Selects the symbol set most suited to the needs of the host computer.
(PC8, PC850, PC852, PC858, PC8DN, PC8TK, PC1004, PSTEXT, ROMAN8, ROMAN9, WIN30,
WINBALT, WINL1, WINL2, WINL5, DESKTOP, ISO4, ISO6, ISO11, ISO15, ISO17, ISO21, ISO60, ISO69,
ISOL1, ISOL2, ISOL5, ISOL6, ISOL9, LEGAL, MCTEXT, PC775)
8. CUSTOM PAPER Sets whether to use a custom paper size.
OFF Disables you to specify a custom paper size.
ON Enables you to specify a custom paper size.
1. UNIT OF MEASURE Selects the unit of measurement to specify a custom paper size.
INCHES
MILLIMETERS –
–
2. X DIMENSION Specifies the horizontal size of the custom paper.
(5.83"-17.00" (148 mm-432 mm))
* 1 Indicates the item that appear only for the imageCLASS MF7480/MF7470.
