display vlan config 167
Table 26 describes the fields in this display.
See Also
„
clear security L2-restrict on page 153
„
set security L2-restrict on page 171
„
set vlan port on page 173
„
set vlan tunnel-affinity on page 174
Table 26 Output for display vlan config
Field Description
VLAN VLAN number.
Name VLAN name.
Admin Status Administrative status of the VLAN:
„ Down — The VLAN is disabled.
„
Up — The VLAN is enabled.
VLAN State Link status of the VLAN:
„
Down — The VLAN is not connected.
„
Up — The VLAN is connected.
Tunl Affin Tunnel affinity value assigned to the VLAN.
Port Member port of the VLAN. The port can be a physical port or a
virtual port.
„
Physical ports are 10/100 Ethernet or gigabit Ethernet ports on
the WX switch, and are listed by port number.
„
Virtual ports are tunnels to other WX switches in a mobility
domain, and are listed as follows: t:ip-addr, where ip-addr is the
system IP address of the WX switch at the other end of the tunnel.
Note: This field can include MAP access ports and wired
authentication ports, because MSS dynamically adds these ports to a
VLAN when handling user traffic for the VLAN.
Tag Tag value assigned to the port.
Port State Link state of the port:
„
Down — The port is not connected.
„
Up — The port is connected.
