Setting Up Huntgroups
MaxCS 7.5 Administration Manual 231
Setting Up Huntgroups
Set up new huntgroups in the Huntgroup Configuration window.
To add a hunt group,
1.
Click the Add button under the Group List.
Figure 135. Adding a new Hunt Group
2. Type in a group number for the hunt group.
3. Check the Global group check box if you want the group to be visible to other systems within the VoIP
domain. See the sectionEnterprise VoIP Network Management for more information.
4. Click OK.
Establishing Basic Hunt Group Attributes
After you create a hunt group, you can set basic attributes in the Huntgroup Configuration, General tab:
To set Hunt Group information, enter the following information:
• First Name and Last Name – Each with a maximum of 32 characters.
• Password – The default is the system default password set on the Number Plan tab of the System
Configuration window.
A valid password cannot be the same as its hunt group number and must be 4 - 8 digits (numbers or letters
A - Z) in length. Basic password patterns, such as repeated digits (1111), consecutive digit strings (1234),
or digits that match the extension (Ext. 101 using 1012, 9101, 10101, etc.) are not recommended. The
letters map to numbers (on a phone, for example) as follows:
Numbers Letters Numbers Letters
2 A, B, C, a, b, c 6 M, N, O, m, n, o
3 D, E, F, d, e, f 7 P, Q, R, S, p, q, r, s
4 G, H, I, g, h, i 8 T, U, V, t, u, v
5 J, K, L, j, k, l 9 W, X, Y, Z, w, x, y, z
• DID Number – Each hunt group can be assigned a DID number. This number does not have a fixed
length, but the length must be long enough (range 2 - 16) for the system to match the DID incoming call.
• Enable Dial-By-Name Service – Check this box to allow callers to search the list by employee name for
this hunt group extension.
• Description – Describe the purpose of this hunt group.
