Setting up Extensions
MaxCS 7.5 Administration Manual 183
IP Extension Configuration
See “Setting Up IP Extensions” on page 203 for information on configuring this section of the Extension
Configuration General tab.
Phone Display Options
For analog and AltiGen IP phones, the administrator can select what information is to be displayed.
Figure 113. Phone Display options
Depending on the number of display lines on the LCD, the phone can be set up to show two lines of specific
caller information on the display.
In the Phone Display field, use the Number Line and Name Line lists to select the caller information to
display:
• Caller Number
• Caller Name
• DNIS Number
• DNIS Name
• AA Data
• User Data
Note: For most phones, the number line can only display a number. If the Number Line is set to Caller
Name
, DNIS Name, User Data or AA Data, the phone may display “Unknown” on the number line.
Alti-IP 600, IP 705, and IP 805 Phone Display Notes
For the Alti-IP 600, IP 705, and IP 805 models, the Name Line displays caller information under the following
conditions:
• If Name Line is set to Caller Name, it will display caller name. If there is no name information, the number
will be displayed.
Caller ID Transmission
Methods
Specifies how Caller ID will be detected:
• CID between 1st and 2nd ring – Caller ID is received between first and
second ring. (Most common in US/Canada)
• DT-AS+CID prior to ringing – Dual Tone Alerting Signal Caller ID is
received prior to ringing.
• RP-AS+CID prior to ringing – Ring Pulse Alerting Signal Caller ID is
received prior to ringing.
Receive from phone (dB
Gain)
Range -3 ~ +3 db
You can decrease or increase the extension phone's talk volume with this
setting. Default is 0 dB.
Transmit to phone (dB Gain)
Range -3 ~ +3db
You can decrease or increase the extension phone's receiving volume with
this setting. The volume will be lower or higher for the extension user. Default
is 0 dB.
Parameter Description
