• Enabled with SNMP.
• Added into IMC and managed by IMC.
• Not imported as PE devices.
To import CE devices:
1. Click the Service tab.
2. From the navigation tree, select L2VPN Manager > VPN Devices > CE Devices.
The CE Device List page displays all CE devices.
3. Click Import CE on top of the CE Device List area.
The Import Device page appears.
4. Click Select Device to select the CEs to be imported.
There are two methods for selecting devices, By View or using the Advanced option. See "
Adding
Devices by View " and " Adding Devices by Advanced Query ."
5. Highlight the devices you want to select and do one of the followings:
{
To add them to the Selected Devices list, click Add selected .
{
To select all of the devices displayed in the Devices Found list, click Add all .
{
To remove one or more, select them and click Remove selected .
{
To remove all of the selected devices, click Remove all .
6. Confirm that the devices you have found have been added.
7. Click OK to enter the Import Device page.
The selected devices now appear in the page.
8. Verify the imported devices.
{
To add more devices, repeat step 4.
{
To delete devices, select one or multiple devices in the CE Device List and click Delete.
9. Click OK.
You can view the import process and results in the Import Device page.
Adding/Modifying a VCE
1. Click the Service tab.
2. From the navigation tree, select L2VPN Manager > VPN Devices > CE Devices.
The CE Device List page displays all CE devices.
3. Click Add VCE on top of the CE Device List area to enter the Add Non-managed CE page. Or, click
the Modify icon in the Operation field for the VCE to be modified to enter the Modify VCE
page.
4. Configure the following parameters as needed:
{
Device Label—Enter the device label.
101
