Floor Device Wiring Location
Terminal
Block
Default Output Desig-
nator
28 GIOX
Output Module 4 - Slot
2
TB71 Output 1.4.2
29 GIOX
Output Module 4 - Slot
3
TB72 Output 1.4.3
30 GIOX
Output Module 4 - Slot
4
TB72 Output 1.4.4
31 GIOX
Output Module 4 - Slot
5
TB73 Output 1.4.5
32 GIOX
Output Module 4 - Slot
6
TB73 Output 1.4.6
33 GIOX
Output Module 4 - Slot
7
TB74 Output 1.4.7
34 GIOX
Output Module 4 - Slot
8
TB74 Output 1.4.8
l
The Output is the Door Relay for each floor.
l
Cab Request is not yet enabled for GIOX units. Currently your only option is the
default Elevator - No Floor Select value.
