Doors.NET Reference Manual
- 333 -
l
Panel Description - the type of controller panel (by manufacturer and physical char-
acteristics)
l
Description - the names assigned to the individual outputs on that controller
l
Model - the type of device providing output
Review/Edit Input Configuration Parameters
The right pane of the grid lists all information and configuration parameters for the output
selected in the left pane. If an item in the grid is grayed-out it is not changeable.
General
l
Description - enter a descriptive name for this input (128 characters max)
l
Enabled - enable or disable this input
l
Mode - output is active-energized or active-deenergized
l
Follow Schedule - assign this input a time schedule during which it is active
l
Default Pulse Time - the amount of time an output pulsed when active; up to a max-
imum of 18 hours, 12 minutes, 15 seconds
Advanced
l
Output Type - identify the type of output, typically a control point; other output types
may have additional configuration parameters that need to be set
Monitoring
l
Global Trigger - select an event trigger that will be tested when this output creates
an event - if the event matches the trigger, the trigger will activate
Selected Hardware Output Operations
The Selected Hardware tab displays two operation groups with manual operation com-
mands that can be applied to selected inputs in the grid.
NOTE: As is typical with Windows based programs, you can select multiple, random out-
puts or consecutive sets of outputs using the standard Windows Ctrl-Click and Shift-
Click commands.
Selected Items
l
History - list an event history for selected outputs; the pull-down menu beside the
History option allows you to select a specific event on which to display output his-
tory
