Assembling Momentum Components
94 870 USE 101 10 V.2
Section 3.2
Assembling a CPU with an Option Adapter
Overview
Purpose An Option Adapter can only be used in conjunction with a Processor Adapter. It
cannot be used alone with an I/O base.
This section describes how to add an Option Adapter when assembling a
Momentum module and how to remove an Option Adapter from the assembled
module.
In This Section This section contains the following topics:
For This Topic... See Page...
Assembling a Processor Adapter and an Option Adapter 95
Mounting the Assembled Adapters on the I/O Base 98
Disassembling a Module with an Option Adapter 101
