Configuring an M1 CPU with Concept
870 USE 101 10 V.2
359
Accessing and Editing the I/O Map, Continued
Editing the Local
I/O Map,
Continued
Local I/O Only
This screen is always used to I/O Map the local I/O base only. No other I/O base
units can be I/O Mapped on this first screen.
I/O Bus: A
Special Case
If you are I/O Mapping a Processor Adapter which supports I/OBus communication
stations, you will need to go to a separate I/O Map screen for Drop 2. That process
is described in
I/O Mapping an I/OBus Network with Concept on page 361.
Step
Action
3
Double-click on your selection or click the
Result: The I/O base you selected is displayed in the Local Momentum Drop
dialog box.
4
Complete any required fields for Input and Output References.
5
Click the
