Configuring an M1 CPU with Concept
870 USE 101 10 V.2 317
Default Configuration Parameters, Continued
Defaults for an
18.4K Machine This sample PLC Configuration screen shows the default configuration parameters.
Default Values Here are the default parameters:
PLC Configuration
PLC
Exec Id:
Memory Size:
Type: Available Logic Area:
Extended Memory:
Ranges Loadables
Specials Segment Scheduler
Config Extensions
Coils:
Discrete Inputs:
Input Registers:
Holding Registers:
Battery Coil:
Timer Register:
Time of Day:
Data Protection:
Peer Cop:
Hot Standby:
Ethernet:
Profibus DP:
Number installed:
Segments: 1
0
17649
Disabled
Not Applicable
Disabled
Not Applicable
Not Applicable
898
18.43K
171 CCC 960 20-984
000001 - 001536
100001 - 100512
300001 - 300048
400001 - 401872
Parameter 2.4K Machine 12.2K Machine 18.4K Machine
Coils in state RAM 1536 (0 x) 1536 (0 x) 1536 (0 x)
Discrete inputs in state RAM 512 (1 x) 512 (1 x) 512 (1 x)
Input registers in state RAM 48 (3 x) 48 (3 x) 48 (3 x)
Output registers in state RAM 1872 (4 x) 1872 (4 x) 1872 (4 x)
Full logic area (in bytes) 1678 11532 17649
Words of user memory space
for the I/O Map 144 144 144
Memory allocated for
configuration extension None None None
