Overview of Momentum M1 Processor Adapters
20 870 USE 101 10 V.2
Section 1.1
Introducing the M1 Processor Adapters
Overview
Purpose A Momentum M1 Processor Adapter stores and executes the application program,
controlling the local I/O points of its host I/O base and distributed I/O devices on a
common communication bus.
This section describes the front panel components, memory and performance
characteristics of M1 Processor Adapters.
In This Section This section contains the following topics:
For This Topic... See Page...
Front Panel illustration 21
Overview of Ports 22
Memory and Performance Characteristics 24
Power Supply 27
