Configuring an M1 CPU with Concept
870 USE 101 10 V.2 311
Selecting an M1 Processor Adapter
Introduction This section describes how to select an M1 Processor Adapter for a new project
using Concept 2.2.
F
Procedure Follow the steps below to select an M1 Processor Adapter for a new project.
Continued on next page
Note: For a full description of Concept, refer to the set of manuals shipped with
the software.
Step Action
1 From the File menu, select New Project.
Result: A new project is opened and the file name [untitled] appears over
the menu bar.
2 From the Project menu, select Configurator.
Result: The PLC Configuration screen appears.
PLC Configuration
PLC
Exec Id:
Memory Size:
Type: Available Logic Area:
Extended Memory:
Ranges Loadables
Specials Segment Scheduler
Config Extensions ASCII
Coils:
Discrete Inputs:
Input Registers:
Holding Registers:
Battery Coil:
Timer Register:
Time of Day:
Data Protection:
Peer Cop:
Hot Standby:
Ethernet:
Profibus DP:
Number installed:
Segments:
Number of Messages:
Mesage Area Size:
Number of Ports:
