Configuring an M1 CPU with Concept
870 USE 101 10 V.2
325
Establishing Configuration Extension Memory for Peer Cop, Continued
Procedure
From the PLC Configuration screen, follow the steps below to enable Peer Cop and
adjust the amount of Configuration Extension memory:
Continued on next page
Step
Action
1
From the Configure menu, select Config extensions OR double-click anywhere in
the Config Extensions region of the screen.
Result: The Configuration Extension dialog box appears.
2
Click the check box next to Peer Cop, then click OK.
Result: Peer Cop status changes from Disabled to Enabled in the PLC
Configuration screen.
Data Protection:
Disabled
Peer Cop:
Enabled
Hot Standby:
Not Applicable
Ethernet:
0
Profibus DP:
Not Applicable
Config Extensions
