870 USE 101 10 V.2 171
Using the I/OBus Port
At a Glance
Purpose Three Momentum components offer I/OBus master capabilities:
l 171 CCS 760 00 Processor Adapter
l
171 CCC 760 10 Processor Adapter
l 171 CCC 960 20 and 171 CCC 960 30 Processor Adapters
This section describes the I/OBus port, explains how I/OBus works, provides
guidelines for creating I/OBus networks with Momentum components, and
describes recommended cable accessories.
In This Chapter This chapter contains the following topics:
For This Topic... See Page...
I/O Bus Port 172
How I/OBus Works 173
Network Status Indication in the M1 Ethernet Module 174
Guidelines for I/OBus Networks 175
Cable Accessories 177
Pinouts 179
