Configuring an M1 CPU with Concept
870 USE 101 10 V.2 323
Changing the Size of the I/O Map, Continued
Procedure From the PLC Configuration screen, follow the steps below to change the size of
the I/O Map:
Step Action
1 From the Configure menu, select I/O Map.
Result: The I/O Map dialog box appears.
2 Modify the size of the I/O Map by typing a new value in the Expansion Size field
OR by adjusting the sliding scale.
3 Click the button.
