Configuring an M1 CPU with Concept
870 USE 101 10 V.2 329
Reserving and Monitoring a Battery Coil, Continued
Reserving a
Battery Coil,
Continued
Continued on next page
Step Action
2 Click the check box next to Battery Coil.
3 Type a number from the range of available 0 xxxx references in the box marked
O x.
Example: If you have set the range of 0 x’s at 000001...001536, you might want to
enter the reference value of the last coil–1536.
4 Click the button.
Result: The dialog box closes and the register you have specified is displayed on
the PLC Configuration screen.
Specials
Battery Coil
Timer Register
Time Of Day
0x
4x
4x -400007
1536
1872
1865
Allow Duplicate Coils First Coils Address:
Watchdog Timeout (ms*10):
Online Editing Timeslice (ms):
OK Cancel Help
25
20
Maximum
Specials
Battery Coil
Timer Register
Time Of Day
0x
4x
4x -400007
1536
1872
1865
Allow Duplicate Coils First Coils Address:
Watchdog Timeout (ms*10):
Online Editing Timeslice (ms):
OK Cancel Help
25
20
Maximum
1536
