Ladder Logic Elements and Instructions
410 870 USE 101 10 V.2
DX Loadable Support
Introduction The M1 CPUs can use DX loadable instructions, which support optional software
products that can be purchased for special applications. DX loadables provide the
user with special ladder logic functions.
Loaded on
Page 0 The code for DX loadables gets loaded into the Page 0 area. Thus, for every word
of DX loadable that is loaded, one word of Page 0 becomes unavailable for other
use (such as application logic).
Limited
Functionality DX loadables are limited in the functionality they can provide because they do not
provide storage for variables and are limited in their size.
M1 Support M1 supports only loadables targeted for 80x86 microprocessors running in 16-bit
real mode that have not made any hard-coded hardware assumptions (e.g., the
address and format of the TOD clock). Obviously, there must be enough available
memory to fit the loadable.
Saved to Flash Since DX loadables are stored in Page 0 memory, they are saved whenever a
save-to-Flash operation is initiated.
