Configuring an M1 CPU with Modsoft
244 870 USE 101 10 V.2
Accessing and Editing the I/O Map, Continued
Editing the Local
I/O Map
Continued on next page
Step Action
3 Assign the appropriate state RAM reference(s) to the unit.
Example: In the screen below, one 3 x register (300001) has been assigned for the
input points and one 4 x register (400001) has been assigned for the output points:
4 Press to return to the Configuration Overview editor.
