Configuring a Modbus Plus
Network in Modsoft with Peer Cop
At a Glance
Purpose
Communication transactions over Modbus Plus are defined in Modsoft 2.6 by a
configuration tool called Peer Cop. This section uses examples to explain how to
use Peer Cop to configure the two types of network architecture:
l
An I/O network, where the Peer Cop of the CPU defines all the communication
transactions over the full network.
l
A supervisory network with two or more CPUs communicating with each other
and with additional devices on the network.
In This Chapter
This chapter contains the following sections:
For This Topic...
See Section...
On Page...
Getting Started
1
258
Using Modbus Plus to Handle I/O
2
263
Passing Supervisory Data over Modbus Plus
3
281
