Configuring an M1 CPU with Concept
870 USE 101 10 V.2 345
Accessing the Ethernet / I/O Scanner Screen
Introduction Ethernet address and I/O scanning parameters can be modified using the
Ethernet / I/O Scanner dialog box in Concept 2.2.
How to Get There From the Configure menu, select Ethernet / I/O Scanner... . This menu option will
only be available if you have selected an M1 Processor Adapter with an Ethernet
port.
Continued on next page
