Configuring an M1 CPU with Concept
870 USE 101 10 V.2 315
Default Configuration Parameters
Overview This section describes the default configuration parameters.
Defaults for a
2.4K Machine This sample PLC Configuration screen shows the default configuration parameters.
Continued on next page
PLC Configuration
PLC
Exec Id:
Memory Size:
Type: Available Logic Area:
Extended Memory:
Ranges Loadables
Specials Segment Scheduler
Config Extensions
Coils:
Discrete Inputs:
Input Registers:
Holding Registers:
Battery Coil:
Timer Register:
Time of Day:
Data Protection:
Peer Cop:
Hot Standby:
Ethernet:
Profibus DP:
Number installed:
Segments: 1
0
1297
Disabled
Not Applicable
Disabled
Not Applicable
Not Applicable
898
2.46K
171 CSS 700 10
000001 - 001536
100001 - 100512
300001 - 300048
400001 - 401872
