Configuring an M1 CPU with Concept
310 870 USE 101 10 V.2
Section 12.1
Configuring the Processor Adapter
Overview
Purpose This section describes how to configure a Momentum M1 Processor Adapter using
Concept 2.2.
In This Section This section contains the following topics:
For This Topic... See Page...
Selecting an M1 Processor Adapter 311
Default Configuration Parameters 315
Changing the Range of Discrete and Register References 318
Changing the Size of the Full Logic Area 320
Understanding the Number of Segments 321
Changing the Size of the I/O Map 322
Establishing Configuration Extension Memory for Peer Cop 324
