Schneider Electric Processor Adapter - Manual (Page 138)

Using the Modbus Ports
138 870 USE 101 10 V.2
Pinouts for Modbus RS485 Networks, Continued
Modbus RS485
Connector “T”
(DB9 Base) The illustration below shows the pinout for the Modbus RS485 Connector “T” (DB9
base):
Continued on next page
