Using Peer Cop with Modsoft
870 USE 101 10 V.2 273
Specifying References for Input Data, Continued
Procedure Follow the steps in the table below to define the specific input in Peer Cop.
Continued on next page
Step Action
1 Move the cursor to the REFERENCE column of the SPECIFIC INPUT field, using the
cursor arrow keys.
2 Type the value 300016 in the REFERENCE column of the SPECIFIC INPUT field,
then push .
Result: The cursor moves into the LEN column of the SPECIFIC INPUT field.
