Configuring an M1 CPU with Modsoft
220 870 USE 101 10 V.2
Changing the Size of the I/O Map
Introduction The default size of the I/O Map and your options vary, depending on whether or not
your Processor Adapter supports an I/OBus network.
Processors For
I/O Bus
Networks With I/OBus, an I/O Map table is used to define the number, location, and type of
I/O devices on the network bus.
All Other
Processors Other Processor Adapters only use the I/O Map for local I/O. The default of 32
words is sufficient for any Momentum I/O base. Depending on the requirements of
your I/O base, you may be able to reduce the number of words to the minimum, 17,
in order to increase the size of the full logic area.
Continued on next page
Default 512 words
Minimum 17 words
Default 32 words
Minimum 17 words
