Configuring an M1 CPU with Concept
354
870 USE 101 10 V.2
Completing the I/O Configuration
Introduction
This section describes how to complete your Ethernet I/O configuration using the
Copy, Cut, Paste, Delete, Sort and Fill Down buttons.
Copy and Paste
To save time when typing similar read and write commands, you may copy and
paste entire rows within your configuration. Follow the steps in the table below:
Continued on next page
Step
Action
1
Select the row you want to copy by clicking on the row number at the far left.
2
Click the Copy button above the I/O configuration list.
3
Select the row where you would like to paste the data (by clicking on the row
number at the far left).
4
Click the Paste button above the I/O configuration list.
