Configuring an M1 CPU with Concept
328 870 USE 101 10 V.2
Reserving and Monitoring a Battery Coil
Introduction Since the Option Adapter does not have an LED to indicate when the battery is low,
we recommend that you reserve a 0
x reference to monitor the health of the battery.
This section describes how to reserve and monitor a battery coil, using the Specials
dialog box in Concept 2.1.
Reserving a
Battery Coil From the PLC Configuration screen, perform the steps in the following table to
reserve a battery coil.
Continued on next page
Note: The 171 CCC 960 30 and 171 CCC 980 30 require Concept 2.2 with
service release 2.
Step Action
1 From the Configure menu, select Specials... OR double-click on any field in the
Specials region of the dialog box.
Result: The Specials dialog box appears.
Specials
Battery Coil
Timer Register
Time Of Day
0x
4x
4x -400007
1536
1872
1865
Allow Duplicate Coils First Coils Address
Watchdog Timeout (ms*10):
Online Editing Timeslice (ms):
OK Cancel Help
25
20
